Critical Power Product Examples

BBU_ 10.8V 86Wh

12V 1.5kW BBU module

• Regulated 12V

• 125A continuous output capability for >30 seconds

• 4S3P configuration using 18650 cells

• Hot swappable with integrated DC/DC charger (OR’ing)

• Load sharing capability between multiple BBU units

• Calendar Life: 2 years storage; 5+ year operational life



12V / 16 AH BBU12V 3kW AC/DC Power Shelf

• Regulated 12V (BBU + peak load assist)

• 250A continuous output capability for >90 seconds from 0°C to 47°C

• 4S12P configuration using 18650 NMC cells

• Hot swappable with integrated AC/DC charger (<3 hours)

• Load sharing capability between multiple BBU units

• DSP controlled multi-channel high efficiency DC/DC Buck/Boost topology for rapid load response and output stability



48V / 2-3KW UPS

48V 2-3kW UPS

• Unregulated 48V

• 40A or 60A continuous output capability for >5 minutes

• 14S6P configuration using 18650 NMC cells

• 1U height form factor for rack mounting

• Load sharing capability between multiple BBU units



12V BBU OpenEde Prototype CAD12V 1.6kW BBU openEdge

• Regulated 12V Output x 133A

• 1.6kW for 5-8 minutes

• -5°C to 60°C Discharge Operation

• 6S6P configuration using 18650 cells

• 5+ year life (600+ cycles)

• Fanless design

• Full feature BMS (Protection, Fuel Gauge, Charging & SMBus communication)

• Application: Far Edge, IoT, 5G Data



ORV3 48V BBU Prototype CAD48V 18kW BBU openRack OVR3ORV3 48V BBU - 1 Module

• 48V Nominal x 60A Discharge

• 6 BBU modules x 3kW each (18kW Total System Power)

• 5 minute runtime

• Parallel stackable

• 5+ year life (600+ cycles)

• Application: Hyperscale Data Center
